Fuel Module HP,Corvette 2003.5-2013 Z06*

Item #: TU476-1

$279.99

per EACH
This is an obsolete Item



TU476-1 - HP Fuel Module, GM Corvette C5/C6 Z06 2003 1/2-2013

GM/TI OEM fuel pump module. Complete new in box features:
  1. Direct-fit module for 2003 1/2 C5 and all C6 Corvettes (excluding ZR1 - see note below for fitment)
  2. High-performance turbine pump with jet-pump - keeps pump submerged under low tank conditions for cornering and acceleration. Prevents motor detonation.
  3. Z06 HO upgrade over stock C5/C6 pump module (see performance chart below)
  4. PnP with factory wiring and fittings (1)
  5. Level sender and float arm included ((2)
  6. Fuel pressure regulator included
  7. Filter socks
  8. Tank gasket
  9. Instructions

DIRECT-FIT REPLACEMENT

GM AC DELCO DELPHI NOTES
19149687 M10059 FG1092 2
19149082 M10059 2
19149685 M10059 2
88967315 M10059 FG1091 2
19133441 M10059 2
19149689 M10057 FG1091 / FG1092 2
19207959 FG1092 2

1. We highly recommend using our FPWH-008 upgrade harness to maximize fuel flow and eliminate electrical issues with the factory wiring when upgrading to this module. This harness is a 100% requirement if you are running any type of fuel pump voltage booster. This item is listed under add-ons to the right of this this page.

2. All GM / Delphi / AC Delco part numbers do not include the factory sensor assembly where the TI unit we carry does.


DIRECT-FIT UPGRADE

GM AC DELCO DELPHI NOTES
19133425 M10014 2
10339526 MU1251 FG1091 2
19133430 MU1410 FG1091 2
10337590 MU1361 FG1091 2
19149227 FG1091 FG1091 2

This module is direct-fit in all C5 Corvettes manufactured 2003 1/2 and later with VIN # 114931 (last six digits) and up as well as all C6 Corvettes through 2013 excluding the ZR1.

IF YOU ARE UNSURE OF YOUR MODULE NUMBER PLEASE E-MAIL US YOUR VIN # BEFORE YOU ORDER. WE CANNOT ALLOW RETURNS ON ANY OPEN BOX PUMPS PERIOD!

PERFORMANCE DATA
TU475 is the factory module fitted to all standard Corvettes.
TU476 is the factory module fitted to all Z06 and special edition HP Corvettes.

PERFORMANCE DATA
TU475 is the factory module fitted to all standard Corvettes.
TU476 is the factory module fitted to all Z06 and special edition HP Corvettes.



OE APPLICATION CHARTS

TU475



TU476
